Cat 3512 Diesel Generators

Available in 1100 kW, 1250 kW, 1400 kW, 1500 kW and 1750 kW ratings
1400 kw diesel generator
REQUEST A QUOTE
Standby Ratings 1100 kw / 1250 kW / 1400 kW / 1500 kW / 1750 kW
Prime Ratings 1000 kW / 1135 kW / 1275 kW / 1360 kW
Frequency 60 Hz
Voltage 380V to13800V
Fuel Diesel
Engine Cat 3512
Controls EMCP 4
Optional Enclosure Fully weatherproof and sound attenuated
Optional Sub Base Fuel Tank  ULC S601
Dimensions (LxWxH) 207 x 90 x 92  to
243.2 x 90 x 110 inches
Weight (skid only) 22,210 to 32,660 lbs
Drawings Request Drawings
Specs 1000 kW 3512 specs
1250 kW 3512 specs
1400 kW 3512B specs
1500 kW 3512B specs
1500 kW 3512C specs
1750 kW 3512C specs

Related Products

1000 kW diesel generator
Caterpillar C32 Diesel Generator
Standby
Ratings		 1000 kW
Prime
Ratings		 910 kW
Voltage 220V to 4160V
Frequency 60 Hz
Dimensions 164 x 664 x 85 inches
Weight 14,700 lbs
1,000 kW
1750 kw diesel generator
Caterpillar 3516 Diesel Generator
Standby
Ratings		 1750 kW / 2000 kW / 2250 kW / 2500 kW / 2750 kW
Prime Ratings 1600 kW / 1825 kW / 2250 kW / 2500 kW
Voltage 380V to 13800V
Frequency 60 Hz
Dimensions
 244x90x95 - 304x104x132"
Weight 35,880 to 40,700 lbs
1750 kW to 2750 kW
4 MW diesel generators
Caterpillar C175-16 Diesel Generator
Standby
Ratings		 3000 kW / 3100 kW
Prime
Ratings		 2725 kW / 2825 kW
Voltage 480V to13800V
Frequency 60 Hz
Dimensions
 314 x 114 x 135 inches
Weight 50,500 lbs
3000 to 3100 kW
